11-5
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 11 Change DWDM Card Settings
DLP-G200 Change the OSCM and OSC-CSM Optical Service Channel Thresholds
Step 4 Click Apply. If the change affects traffic, a warning message displays. Click Yes to complete the
change.
Step 5 Return to your originating procedure (NTP).
DLP-G200 Change the OSCM and OSC-CSM Optical Service Channel
Thresholds
Step 1 In node view, double-click the OSCM or OSC-CSM card where you want to change the optical line
threshold settings.
Step 2 Click the Provisioning > OC3 Line > SONET Thresholds tabs.
Step 3 Modify any of the settings described in Table 11-2. The provisionable parameters are listed in the
options column in the table.
AINS Soak Sets the automatic in-service soak period.
• Duration of valid input signal, in hh.mm format, after
which the card becomes in service (IS) automatically
• 0 to 48 hours, 15-minute increments
Type Defines the port as SONET or SDH. The
Enable Sync Msg field and the Send Do Not
Use field must be disabled before the port can
be set to SDH.
From the drop-down list, choose one of the following:
• SONET
• SDH
Purpose This task changes the OC-3 (STM-1) SONET (SDH) thresholds settings
for the OSC signal transmitted by the OSCM and OSC-CSM cards.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 11-2 OSCM and OSC-CSM Cards SONET Threshold Settings
Parameter Description Options
Port Displays the port number Display only
CV Coding violations Numeric. Can be set for 15-minute or one-day intervals for
Line or Section (Near and Far End). Select the bullet and click
Refresh.
ES Errored seconds Numeric. Can be set for 15-minute or one-day intervals for
Line or Section (Near and Far End). Select the bullet and click
Refresh.
Table 11-1 OSCM and OSC-CSM Card OC-3 Settings (continued)
Parameter Description Options
