Cisco ONS 15454 DWDM User Manual

17-16
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.2.1 1+1 Protected Flexible Terminal Node
Figure 17-16 1+1 Protected Single-Span Link with Hub Nodes
Figure 17-17 shows a 1+1 protected single-span link with active OADM nodes. This node type can be
used in a hybrid configuration.
OPT-BST
110608
OPT-PRE
DCU
32DMX-0
32MUX-0
32MUX-0
32DMX-0
TCC
OPT-BST
Hub node
TCCAIC-I
OPT-PRE
DCU
DCU
Client
equipment
Client
equipment
32MUX-0
32DMX-0
OSCM
OSCM
TCC
Hub node
TCC AIC-I
OPT-BST
OPT-PRE
OSCM
32DMX-0
32MUX-0
DCU
OPT-BST
OPT-PRE
OSCM

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
