9-2
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 9 Monitor Performance
NTP-G73 Change the PM Display
NTP-G73 Change the PM Display
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node that you want to monitor. If you
are already logged in, continue with Step 2.
Step 2 As needed, use the following tasks to change the display of PM counts:
• DLP-G131 Refresh PM Counts at 15-Minute Intervals, page 9-2
• DLP-G132 Refresh PM Counts at One-Day Intervals, page 9-3
• DLP-G133 View Near-End PM Counts, page 9-4
• DLP-G134 View Far-End PM Counts, page 9-5
• DLP-G135 Reset Current PM Counts, page 9-6
• DLP-G136 Clear Selected PM Counts, page 9-7
• DLP-G137 Set Auto-Refresh Interval for Displayed PM Counts, page 9-8
• DLP-G138 Refresh PM Counts for a Different Port, page 9-9
Stop. You have completed this procedure.
DLP-G131 Refresh PM Counts at 15-Minute Intervals
Step 1 In node view (single-shelf mode), or shelf view (multishelf mode), double-click the DWDM, TXP, or
MXP card where you want to change the PM count display interval. The card view appears.
Purpose This procedure enables you to change the display of PM counts by
selecting drop-down list or radio button options in the Performance
window.
Tools/Equipment None
Prerequisite Procedures Before you monitor performance, be sure you have created the
appropriate circuits and provisioned the card according to your
specifications. For more information, see Chapter 7, “Create Channels
and Circuits,” Chapter 5, “Provision Transponder and Muxponder
Cards,” and Chapter 11, “Change DWDM Card Settings.”
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
Purpose This task changes the window view to display PM counts in 15-minute
intervals.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
