Chapter 4 Perform Node Acceptance Tests
DLP-G269 Verify the 32DMX-O Power
DLP-G269 Verify the 32DMX-O Power
Step 1 Display the 32DMX-O card in card view.
Step 2 Click the Provisioning > Optical Chn > Parameters tabs.
Step 3 Change the Admin State for the appropriate port to OOS,DSLB (ANSI) or Locked,disabled (ETSI).
Step 4 Verify that the VOA Power Ref reaches the provisioned setpoint.
Step 5 (Optional) Connect a power meter to the CHAN TX 01 port through the patch panel. Verify that the
physical optical power value coming from drop Port 1 on the west 32DMX-O card is consistent with the
value read (the maximum allowed error is +/– 0.5 dBm).
Step 6 Return to your originating procedure (NTP).
DLP-G270 Verify the 32DMX Power
Step 1 Display the 32DMX card in card view.
Step 2 Click the Provisioning > Optical Chn > Parameters tabs.
Step 3 Change the Admin State for Port 33 to OOS,MT (ANSI) or Locked,maintenance (ETSI)
Step 4 Verify that the VOA Power Ref reaches the provisioned setpoint.
Step 5 (Optional) Connect a power meter to the CHAN TX 01 port through the patch panel. Verify that the
physical optical power value coming from drop Port 1 on the west 32DMX card is consistent with the
value read (the maximum allowed error is +/– 1 dBm).
Step 6 Change the Admin State for Port 1 to OOS,DSLB (ANSI) or Locked,disabled (ETSI).
Step 7 Return to your originating procedure (NTP).
Purpose This task verifies that the 32DMX-O card is provisioned to the correct
power.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
Purpose This task verifies that the 32DMX card is provisioned to the correct power.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
