Cisco ONS 15454 DWDM - Amplified TDM Node

17-27
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.2.6 Amplified TDM Node
Figure 17-26 Amplified TDM Example with an OPT-BST Amplifier
Figure 17-27 shows the first amplified TDM node channel flow scenario configured with OPT-BST
amplifiers.
Figure 17-27 Amplified TDM Channel Flow Example With OPT-BST Amplifiers
Figure 17-28 shows the second amplified TDM node configuration scenario with client cards,
AD-1C-xx.x cards, OPT-BST amplifiers, OPT-PRE amplifiers, and FlexLayer filters.
OPT-BST W
Blank
DCU
Air ramp
DCU
TCC2/TCC2P
XC10G
XC10G
TCC2/TCC2P
AIC-I
110435
TXP, MXP or ITU-T line card W
TXP, MXP or ITU-T line card W
TXP, MXP or ITU-T line card W
TXP, MXP or ITU-T line card W
TXP, MXP or ITU-T line card E
TXP, MXP or ITU-T line card E
TXP, MXP or ITU-T line card E
TXP, MXP or ITU-T line card E
TXP, MXP or ITU-T line card E
TXP, MXP or ITU-T line card E
96896
OPT-BST
TXP
MXP
LC
OPT-BST
DCU
DCU
TXP
MXP
LC
