Appendix C DWDM Administrative and Service States
C.3.5 Transponder/Muxponder Card Service State Transitions
OOS-AU,FLT (ANSI)
Unlocked-disabled,failed (ETSI)
Pull the card. OOS-AU,UEQ (ANSI)
Unlocked-disabled,unequipped (ETSI)
Delete the card. OOS-AUMA,UAS (ANSI)
Locked-disabled,unassigned (ETSI)
Change the administrative state
to OOS,MT (ANSI) or
Locked,maintenance (ETSI).
OOS-AUMA,FLT & MT (ANSI)
Locked-disabled,failed & maintenance
(ETSI)
Reset the card. OOS-AU,SWDL (ANSI)
Unlocked-disabled,softwareDownload
(ETSI)
Alarm/condition is cleared. IS-NR (ANSI)
Unlocked-enabled (ETSI)
OOS-AU,MEA (ANSI) Pull the card. OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
Delete the card. If the card is valid:
• OOS-AUMA,UAS (ANSI)
• Locked-disabled,unassigned (ETSI)
If the card is invalid:
• OOS-AUMA,MEA & UAS (ANSI)
• Locked-disabled,mismatchOfEquipment
& unassigned (ETSI)
Change the administrative state
to OOS,MT (ANSI) or
Locked,maintenance (ETSI).
OOS-AUMA,MT & UEQ (ANSI)
Locked-disabled,maintenance & notInstalled
(ETSI)
OOS-AU,SWDL (ANSI)
Locked-disabled,softwareDownload
(ETSI)
Restart completed. IS-NR (ANSI)
Unlocked-enabled (ETSI)
Pull the card. OOS-AU,UEQ (ANSI)
Locked-disabled,notInstalled (ETSI)
Table C-8 ONS 15454 Transponder/Muxponder Card Service State Transitions (continued)
Current Service State Action Next Service State
