C.3.5 Transponder/Muxponder Card Service State Transitions
OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Change the administrative state
to OOS,MT (ANSI) or
Locked,maintenance (ETSI).
OOS-AUMA,MEA & MT (ANSI)
Locked-disabled,mismatchOfEquipment &
maintenance (ETSI)
Pull the card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Delete the card. If the card is valid:
• OOS-AUMA,UAS (ANSI)
• Locked-disabled,unassigned (ETSI)
If the card is invalid:
• OOS-AUMA,MEA & UAS (ANSI)
• Locked-disabled,mismatchOfEquipment
& unassigned (ETSI)
OOS-AU,AINS & SWDL (ANSI)
Unlocked-disabled,automaticInService &
softwareDownload (ETSI)
Restart completed. IS-NR (ANSI)
Unlocked-enabled (ETSI)
Pull the card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Insert a valid card. OOS-AU,AINS & SWDL (ANSI)
Unlocked-disabled,automaticInService &
softwareDownload (ETSI)
Insert an invalid card. OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Delete the card. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled
(ETSI)
Change the administrative state
to OOS,MT (ANSI) or
Locked,maintenance (ETSI).
OOS-AUMA,MT & UEQ (ANSI)
Locked-disabled,maintenance & notInstalled
(ETSI)
Table C-8 ONS 15454 Transponder/Muxponder Card Service State Transitions (continued)
Current Service State Action Next Service State
