Chapter 16 Card Reference
16.13 SFP and XFP Modules
16.13 SFP and XFP Modules
This section describes the SFPs and 10-Gbps SFPs (XFPs) that can be used with some transponder and
muxponder cards. To install SFPs or XFPs, see the “DLP-G63 Install an SFP or XFP” task on page 3-45.
In CTC, SFPs/XFPs are called pluggable port modules (PPMs). To provision SFPs/XFPs and change the
line rate for multirate PPMs, see the “NTP-G128 Manage Pluggable Port Modules” procedure on
page 5-2.
16.13.1 Compatibility by Card
Table 16-69 lists the transponder and muxponder cards and their compatible SFPs/XFPs.
Caution Only use SFPs/XFPs certified for use in Cisco Optical Networking Systems (ONSs). The qualified Cisco
SFP/XFP pluggable module’s top assembly numbers (TANs) are provided in Table 16-69.
Table 16-69 SFP/XFP Card Compatibility
Card
Compatible SFP/XFP
(Cisco Product ID)
Cisco Top Assembly
Number (TAN)
MXP_2.5G_10G (ONS 15454 SONET/SDH) 15454-SFP-OC48-IR=
ONS-SE-2G-S1=
10-1975-01
10-2017-01
MXP_2.5G_10E (ONS 15454 SONET/SDH) 15454-SFP-OC48-IR=
ONS-SE-2G-S1=
ONS-SE-2G-L2=
10-1975-01
10-2017-01
10-2013-01
MXP_MR_2.5G
MXPP_MR_2.5G
15454-SFP-GE+-LX=
15454E-SFP-GE+-LX=
15454-SFP-GEFC-SX=
15454E-SFP-GEFC-S=
10-1832-03
10-1832-03
10-1833-01
10-1833-02
TXP_MR_2.5G (ONS 15454 SONET/SDH)
TXPP_MR_2.5G (ONS 15454 SONET/SDH)
15454-SFP3-1-IR=
15454E-SFP-L.1.1=
15454-SFP12-4-IR=
15454E-SFP-L.4.1=
15454-SFP-OC48-IR=
15454E-SFP-L.16.1=
ONS-SE-2G-S1=
15454-SFP-200=
15454E-SFP-200=
15454-SFP-GEFC-SX=
15454E-SFP-GEFC-S=
15454-SFP-GE+-LX=
15454E-SFP-GE+-LX=
ONS-SE-2G-L2=
10-1828-01
10-1828-01
10-1976-01
10-1976-01
10-1975-01
10-1975-01
10-2017-01
10-1750-01
10-1750-01
10-1833-01
10-1833-02
10-1832-01
10-1832-02
10-2013-01
TXP_MR_10E (ONS 15454 SONET/SDH) ONS-XC-10G-S1 10-2012-01
