9-4
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 9 Monitor Performance
DLP-G133 View Near-End PM Counts
Step 3 If you want to refresh the PM counts for a subtab, click the relevant subtab(s), located along the left side
of the Performance tab.
Note Performance subtabs vary, depending on the card viewed.
Step 4 If you want to refresh the PM counts for a specific port, select the port from the Ports drop-down list
(where available).
Step 5 Click the 1 day radio button.
Step 6 Click Refresh. Performance monitoring appears in 1-day intervals synchronized with the time of day.
Step 7 View the Curr column to find PM counts for the current 1-day interval.
Each monitored performance parameter has corresponding threshold values for the current time period.
If the value of the counter exceeds the threshold value for a particular 1-day interval, a TCA is raised.
The number represents the counter value for each specific PM parameter.
Step 8 View the Prev-n columns to find PM counts for the previous 1-day intervals.
Note If a complete count over a 1-day interval is not possible, the value appears with a yellow
background. An incomplete or incorrect count can be caused by monitoring for less than
24 hours after the counter started, changing node timing settings, changing the time zone
settings, replacing a card, resetting a card, or changing port service states. When the problem is
corrected, the subsequent 1-day interval appears with a white background.
Step 9 Return to your originating procedure (NTP).
DLP-G133 View Near-End PM Counts
Step 1 In node view (single-shelf mode), or shelf view (multishelf mode), double-click the DWDM, TXP, or
MXP card where you want to view near end PM counts. The card view appears.
Step 2 Click the Performance tab.
Step 3 If you want to view the near-end PM counts for a subtab, click the relevant subtab(s), located along the
left side of the Performance tab.
Note Performance subtabs vary, depending on the card viewed.
Purpose This task enables you to view near-end PM counts for the selected card
and port.
Tools/Equipment None
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Retrieve or higher
