5-46
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G228 Change Line OTN Settings for MXP_2.5G_10G and MXP_2.5G_10E Cards
Table 5-27 describes the values on the Provisioning > OTN > FEC Thresholds tab.
Table 5-28 describes the values on the Provisioning > OTN > Trail Trace Identifier tab.
BBE Background block errors Numeric. Can be set for Near End or Far
End, for 15-minute or one-day intervals,
or for SM (OTUk) or PM (ODUk). Select
a bullet and click Refresh.
FC Failure counter Numeric. Can be set for Near End or Far
End, for 15-minute or one-day intervals,
or for SM (OTUk) or PM (ODUk). Select
a bullet and click Refresh.
Table 5-26 MXP_2.5G_10G and MXP_2.5G_10E Muxponder Card ITU-T G.709 Threshold Settings
Parameter Description Options
Table 5-27 MXP_2.5G_10G and MXP_2.5G_10E Muxponder Card FEC Threshold Settings
Parameter Description Options
Port (Display only) Displays the port number. 5
Bit Errors
Corrected
Displays the number of bit errors
corrected during the interval selected.
The interval can be set for 15 minutes or
one day.
Numeric
Uncorrectable
Words
Displays the number of uncorrectable
words during the interval selected. The
interval can be set for 15 minutes or one
day.
Numeric
Table 5-28 MXP_2.5G_10G and MXP_2.5G_10E Muxponder Card Trail Trace Identifier
Settings
Parameter Description Options
Port Sets the port number. The trail trace
identifier is applicable only to the trunk
interface, which handles ITU-T G.709
frames.
• 5
Level Sets the level.
• Section
• Path
Trace Mode Sets the trace mode.
• Off/None
• Manual
