Chapter 22 Management Connectivity Reference
22.4 Routing Table
Entry 1 shows the following:
• Destination (0.0.0.0) is the default route entry. All undefined destination network or host entries on
this routing table are mapped to the default route entry.
• Mask (0.0.0.0) is always 0 for the default route.
• Gateway (172.20.214.1) is the default gateway address. All outbound traffic that cannot be found in
this routing table or is not on the node’s local subnet is sent to this gateway.
• Interface (motfcc0) indicates that the ONS 15454 Ethernet interface is used to reach the gateway.
Entry 2 shows the following:
• Destination (172.20.214.0) is the destination network IP address.
• Mask (255.255.255.0) is a 24-bit mask, meaning all addresses within the 172.20.214.0 subnet can
be a destination.
• Gateway (172.20.214.92) is the gateway address. All outbound traffic belonging to this network is
sent to this gateway.
• Interface (motfcc0) indicates that the ONS 15454 Ethernet interface is used to reach the gateway.
Entry 3 shows the following:
• Destination (172.20.214.92) is the destination host IP address.
• Mask (255.255.255.255) is a 32 bit mask, meaning only the 172.20.214.92 address is a destination.
• Gateway (127.0.0.1) is a loopback address. The host directs network traffic to itself using this
address.
• Interface (lo0) indicates that the local loopback interface is used to reach the gateway.
Entry 4 shows the following:
• Destination (172.20.214.93) is the destination host IP address.
• Mask (255.255.255.255) is a 32 bit mask, meaning only the 172.20.214.93 address is a destination.
• Gateway (0.0.0.0) means the destination host is directly attached to the node.
• Interface (pdcc0) indicates that a DCC interface is used to reach the destination host.
Entry 5 shows a DCC-connected node that is accessible through a node that is not directly connected:
• Destination (172.20.214.94) is the destination host IP address.
• Mask (255.255.255.255) is a 32-bit mask, meaning only the 172.20.214.94 address is a destination.
• Gateway (172.20.214.93) indicates that the destination host is accessed through a node with IP
address 172.20.214.93.
• Interface (pdcc0) indicates that a DCC interface is used to reach the gateway.
4 172.20.214.93 255.255.255.255 0.0.0.0 16853 pdcc0
5 172.20.214.94 255.255.255.255 172.20.214.93 16853 pdcc0
Table 22-8 Sample Routing Table Entries (continued)
Entry Destination Mask Gateway Usage Interface
