Cisco ONS 15454 DWDM User Manual

D-19
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Appendix D Network Element Defaults
D.2.1 ANSI Card Default Settings
D.2.1.5 TXP_MR_10E Card Default Settings
Table D-5 lists the TXP_MR_10E card default settings.
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.15min.ES 87 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.15min.FC 10 (count) 0–72
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.15min.SES 1 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.15min.UAS 3 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.1day.CV 212600 (B2 count) 0–212371200
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.1day.ES 864 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.1day.FC 40 (count) 0–6912
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.1day.SES 4 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.1day.UAS 10 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.15min.CV 21260 (B2 count) 0–2212200
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.15min.ES 87 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.15min.FC 10 (count) 0–72
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.15min.SES 1 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.15min.UAS 3 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.1day.CV 212600 (B2 count) 0–212371200
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.1day.ES 864 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.1day.FC 40 (count) 0–6912
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.1day.SES 4 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.line.nearend.1day.UAS 10 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.15min.CV 10000 (B1 count) 0–2151900
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.15min.ES 500 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.15min.SEFS 500 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.15min.SES 500 (seconds) 0–900
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.1day.CV 100000 (B1 count) 0–206582400
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.1day.ES 5000 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.1day.SEFS 5000 (seconds) 0–86400
MXPP-MR-2_5G.pmthresholds.trunk.section.nearend.1day.SES 5000 (seconds) 0–86400
Table D-4 MXPP_MR_2.5G Card Default Settings (ANSI) (continued)
Default Name Default Value Default Domain
Table D-5 TXP_MR_10E Card Default Settings (ANSI)
Default Name Default Value Default Domain
TXP-MR-10E.config.client.AINSSoakTime 08:00 (hours:mins) 00:00, 00:15, 00:30 .. 48:00
TXP-MR-10E.config.client.AisSquelchMode Squelch Ais, Squelch

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
