Appendix D Network Element Defaults
D.2.1 ANSI Card Default Settings
MXPP-MR-2_5G.opticalthresholds.client.warning.15min.LowTxPo
wer
-7.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighLaser
Bias
85.5 (%) 0.0, 0.1, 0.2 .. 100.0
MXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighRxPo
wer
2.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighTxPo
wer
2.5 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.client.warning.1day.LowRxPo
wer
-20.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXPP-MR-2_5G.opticalthresholds.client.warning.1day.LowTxPow
er
-7.5 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXPP-MR-2_5G.opticalthresholds.trunk.alarm.HighLaserBias 98.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXPP-MR-2_5G.opticalthresholds.trunk.alarm.HighRxPower -8.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.alarm.HighTxPower 30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.alarm.LowRxPower -25.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXPP-MR-2_5G.opticalthresholds.trunk.alarm.LowTxPower -40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighLase
rBias
95.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighRxP
ower
-7.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighTxP
ower
30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowRxPo
wer
-24.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowTxPo
wer
-40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighLaser
Bias
96.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighRxPo
wer
-7.3 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighTxPo
wer
30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowRxPow
er
-24.7 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowTxPow
er
-40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXPP-MR-2_5G.pmthresholds.trunk.line.farend.15min.CV 21260 (B2 count) 0–2212200
Table D-4 MXPP_MR_2.5G Card Default Settings (ANSI) (continued)
Default Name Default Value Default Domain
