DLP-G304 Provision the MXP_2.5G_10G and MXP_2.5G_10E Client Port Alarm and TCA Thresholds
DLP-G304 Provision the MXP_2.5G_10G and MXP_2.5G_10E Client Port Alarm
and TCA Thresholds
Step 1 In node view, double-click the MXP_2.5G_10G or MXP_2.5G_10E card where you want to change the
client port alarm and TCA settings.
Step 2 Click the Provisioning > Optics Thresholds tabs. The TCA thresholds are shown by default.
Step 3 Referring to Table 5-23, provision the Port N (where N = 1 through 4) TCA thresholds for RX Power
High, RX Power Low, TX Power High, and TX Power Low based on the client interface at the other end.
For additional information about client SFP and XFP interfaces, also known as PPMs, refer to
Appendix B, “Hardware Specifications.”
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
Step 4 Click Apply.
Step 5 Repeat Steps 3 and 4 to provision each additional client port.
Step 6 Under Types, click the Alarm radio button and click Refresh.
Step 7 Referring to Table 5-24, provision the Port N (where N = 1 through 4) Alarm thresholds for RX Power
High, RX Power Low, TX Power High, and TX Power Low based on the client interface that is
provisioned.
Note You must modify 15 Min and 1 Day independently. To do so, choose the appropriate radio button
and click Refresh.
Purpose This task provisions the client port alarm and TCA thresholds for the
MXP_2.5G_10G and MXP_2.5G_10E cards.
Tools/Equipment None
Prerequisite Procedures DLP-G278 Provision the Optical Line Rate, page 5-6
DLP-G46 Log into CTC, page 2-25
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
Table 5-23 MXP_2.5G_10G and MXP_2.5G_10E Card Client Interface TCA Thresholds
Port Type
(by CTC)
Pluggable Port Module
(SFP)
TCA RX
Power Low
TCA RX
Power High
TCA TX
Power Low
TCA TX
Power High
OC-48 ONS-SE-2G-S1 -18 -3 -16 3
15454-SFP-OC48-IR -18 0 -11 6
STM-16 ONS-SE-2G-S1 -18 -3 -16 3
15454E-SFP-L.16.1 -18 0 -11 6
