Chapter 15 Shelf Hardware Reference
15.5 Typical DWDM Rack Layouts
15.5 Typical DWDM Rack Layouts
Typical dense wavelength division multiplexing (DWDM) applications might include:
• 3 ONS 15454 shelves
• 1 Dispersion Compensating Unit (DCU)
• 7 patch panels (or fiber-storage trays)
Or, alternatively:
• 3 ONS 15454 shelves
• 2 DCUs
• 6 patch panels (or fiber-storage trays)
See Figure 15-15 for a typical rack layout.
Note Use the rack layout generated by Cisco MetroPlanner to determine your exact shelf layout.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
