Chapter 6 Turn Up Network
NTP-G57 Create a Logical Network Map
b. For the Standby transponder slot LEDs:
–
DWDM Port is green.
–
Client Port is not illuminated.
Step 18 Confirm that the client or test set at the local site is operating normally with no alarms. If the test set is
reporting active alarms, contact your next level of support.
Note It is normal to see a traffic hit on the test set during a protection switch.
Step 19 From the Switch Commands area below the Selected Group area, click Clear, then click YES to return
the protection group to the original state.
Step 20 Repeat Steps 5 through 19 for each protection group at your site.
Stop. You have completed this procedure.
NTP-G57 Create a Logical Network Map
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at a node on the network where you want to
create the network map. If you are already logged in, continue with Step 2.
Step 2 From the View menu, choose Go to Network View.
Step 3 Change the position of the nodes in the network view according to your site plan.
a. Click a node to select it, then press the Ctrl key while you drag and drop the node icon to a new
location.
b. Repeat Step a for each node you need to position.
Step 4 On the network view map, right-click and choose Save Node Position from the shortcut menu.
Step 5 Click Yes in the Save Node Position dialog box.
CTC opens a progress bar and saves the new node positions.
Purpose This procedure allows a Superuser to create a consistent network view for
all nodes on the network.
Too ls None
Prerequisite Procedures This procedure assumes that network turn-up is complete.
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Superuser
