3-86
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
NTP-G39 Verify OSCM and OSC-CSM Transmit Power
–
ISH—Sets the ISH PDU propagation frequency. Intermediate system NEs send ISHs to other
ESs and ISs to inform them about the IS NETs it serves. The default is 10 seconds. The range
is 10 to 1000 seconds.
–
IIH—Sets the IIH PDU propagation frequency. The IS-IS Hello PDUs establish and maintain
adjacencies between ISs. The default is 3 seconds. The range is 1 to 600 seconds.
–
Metric—Sets the cost for sending packets on the LAN subnet. The IS-IS protocol uses the cost
to calculate the shortest routing path. The default metric cost for LAN subnets is 20. It normally
should not be changed.
Step 7 Click Finish. Ports are automatically placed in service. Until network OSC connections between
adjacent nodes are created, the following alarms might appear:
• SDCC Termination Failure alarm on the OSCM or OSC-CSM card
• LOS-P alarm on the OC-3 port (Port 1) on the OSCM or OSC-CSM card
• OPWR-LFAIL alarm on the OPT-BST or OSC-CSM card
Note After the OSC termination is created, the line ports are placed in service and span power levels
are checked.
Stop. You have completed this procedure.
NTP-G39 Verify OSCM and OSC-CSM Transmit Power
Step 1 Complete the “DLP-G46 Log into CTC” task on page 2-25 at the node where you want to verify the
OSCM or OSC-CSM transmit power. If you are already logged in, continue with Step 2.
Step 2 In the node view shelf graphic, double-click the west OSCM or OSC-CSM card.
Step 3 Click the Maintenance > ALS tabs.
Step 4 From the ALS Mode drop-down list, choose Disable. Click Apply.
Step 5 If a second OSC-CSM or OSCM card is installed, repeat Steps 2 through 4 on the second card. If not, or
if you have completed the steps, continue with Step 6.
Step 6 Complete one of the following tasks, depending on whether you are checking an OSC-CSM or OSCM
card:
• DLP-G313 Verify OSC-CSM Transmit Power, page 3-87
• DLP-G314 Verify OSCM Transmit Power, page 3-89
Purpose This procedure verifies the transmit power of the ONS 15454 OSCM and
the OSC-CSM cards.
Tools/Equipment None
Prerequisite Procedures NTP-G37 Run Automatic Node Setup, page 3-83
Required/As Needed Required
Onsite/Remote Onsite or remote
Security Level Superuser
