Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
April 2006
Chapter 16 Card Reference
16.3.2 MIC-C/T/P FMEC
16.3.2 MIC-C/T/P FMEC
The MIC-C/T/P FMEC provides connection for the BATTERY A input, one of the two possible
redundant power supply inputs. It also provides connection for system management serial port, system
management LAN port, modem port (for future use), and system timing inputs and outputs. Install the
MIC-C/T/P in Slot 24.
The MIC-C/T/P FMEC has the following features:
• Connection for one of the two possible redundant power supply inputs
• Connection for two serial ports for local craft/modem (for future use)
• Connection for one LAN port
• Connection for two system timing inputs
• Connection for two system timing outputs
• Storage of manufacturing and inventory data
For proper system operation, both the MIC-A/P and MIC-C/T/P FMECs must be installed in the shelf.
Figure 16-7 shows the MIC-C/T/P FMEC faceplate.
44 ALMOUP3 N Normally open output pair 4
45 ALMOUP3 P Normally open output pair 4
46 AUDALM0 N Normally open Minor audible alarm
47 AUDALM0 P Normally open Minor audible alarm
48 AUDALM1 N Normally open Major audible alarm
49 AUDALM1 P Normally open Major audible alarm
50 AUDALM2 N Normally open Critical audible alarm
51 AUDALM2 P Normally open Critical audible alarm
52 GND Ground
53 AUDALM3 N Normally open Remote audible alarm
54 AUDALM3 P Normally open Remote audible alarm
55 VISALM0 N Normally open Minor visual alarm
56 VISALM0 P Normally open Minor visual alarm
57 VISALM1 N Normally open Major visual alarm
58 VISALM1 P Normally open Major visual alarm
59 VISALM2 N Normally open Critical visual alarm
60 VISALM2 P Normally open Critical visual alarm
61 VISALM3 N Normally open Remote visual alarm
62 VISALM3 P Normally open Remote visual alarm
Table 16-15 Alarm Interface Pinouts on the MIC-A/P DB-62 Connector (continued)
Pin No. Signal Name Signal Description
