3-32
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 3 Turn Up a Node
DLP-G289 Provision Additional Manual Area Addresses
Note The Router 1 manual area address, System ID, and Selector “00” create the node NSAP address.
Changing the Router 1 manual area address changes the node’s NSAP address.
Note The System ID for Router 1 is the node MAC address. The System IDs for Routers 2 and 3 are created
by adding 1 and 2 respectively to the Router 1 System ID. You cannot edit the System IDs.
Step 1 Click the Provisioning > OSI > Routers > Setup tabs.
Step 2 Chose the router you want provision and click Edit. The OSI Router Editor dialog box appears.
Step 3 In the OSI Router Editor dialog box:
a. Check Enable Router to enable the router and make its primary area address available for editing.
b. Click the manual area address, then click Edit.
c. In the Edit Manual Area Address dialog box, edit the primary area address in the Area Address field.
If you prefer, click Use Mask and enter the edits in the Masked NSAP Entry dialog box. The address
(hexadecimal format) can be 8 to 24 alphanumeric characters (0–9, a–f) in length.
d. Click OK successively to close the following dialog boxes: Masked NSAP Entry (if used), Edit
Manual Area Address, and OSI Router Editor.
Step 4 Return to your originating procedure (NTP).
DLP-G289 Provision Additional Manual Area Addresses
Step 1 Click the Provisioning > OSI > Routers > Setup tabs.
Step 2 Chose the router where you want provision an additional manual area address and click Edit. The OSI
Router Editor dialog box appears.
Step 3 In the OSI Router Editor dialog box:
a. Check Enable Router to enable the router and make its primary area address available for editing.
b. Click the manual area address, then click Add.
Purpose This task provisions the OSI manual area addresses. One primary area and
two additional manual areas can be created for each virtual router.
Tools/Equipment None
Prerequisite Procedures NTP-G22 Verify Common Card Installation, page 3-4
DLP-G288 Provision OSI Routers, page 3-31
DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite or remote
Security Level Provisioning or higher
