5-72
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G238 Change OC-48/STM-16 Settings for MXP_MR_2.5G and MXPP_MR_2.5G Cards
Table 5-44 MXP_MR_2.5G and MXPP_MR_2.5G Muxponder Card Line SONET or SDH Tab Settings
Parameter Description Options
Port # (Display only) Port number. 9 (trunk for MXP_MR_2.5G) or 9 and 10 (trunks for
MXPP_MR_2.5G)
Port Name Provides the ability to assign the specified port a
name.
User-defined. Name can be up to 32 alphanumeric/
special characters. Blank by default.
See the “DLP-G104 Assign a Name to a Port” task on
page 7-10.
Admin State Sets the port service state unless network
conditions prevent the change. For more
information about administrative states, see
Appendix C, “DWDM Administrative and
Service States.”
• IS (ANSI) or Unlocked (ETSI)
• IS,AINS (ANSI) or Unlocked,automaticInService
(ETSI)
• OOS,DSBLD (ANSI) or Locked,disabled (ETSI)
• OOS,MT (ANSI) or Locked,maintenance (ETSI)
Service State Identifies the autonomously generated state that
gives the overall condition of the port. Service
states appear in the format: Primary
State-Primary State Qualifier, Secondary State.
For more information about service states, see
Appendix C, “DWDM Administrative and
Service States.”
• IS-NR (ANSI) or Unlocked-enabled (ETSI)
• OOS-AU,AINS (ANSI) or Unlocked-disabled,
automaticInService (ETSI)
• OOS-MA,DSBLD (ANSI) or
Locked-enabled,disabled (ETSI)
• OOS-MA,MT (ANSI) or
Locked-enabled,maintenance (ETSI)
SF BER
1
Sets the signal fail bit error rate. • 1E-3
• 1E-4
• 1E-5
SD BER
1
Sets the signal degrade bit error rate. • 1E-5
• 1E-6
• 1E-7
• 1E-8
• 1E-9
AINS Soak Sets the automatic in-service soak period.
Double-click the time and use the up and down
arrows to change settings.
• Duration of valid input signal, in hh.mm format,
after which the card becomes in service (IS)
automatically
• 0 to 48 hours, 15-minute increments
Type The optical transport type.
• SONET (ANSI)
• SDH (ETSI)
