Chapter 4 Perform Node Acceptance Tests
DLP-G93 Verify Add and Drop Connections on an OADM Node with OSCM Cards
c. Change the Admin State of the BAND TX port to OOS,MT (ANSI) or Locked,maintenance
(ETSI) for the channel related to the wavelength selected on the tunable laser.
d. Verify that the BAND TX Power value is higher than the default no-power value of –30 dBm.
Step 6 Verify the west 4MD-xx.x (west-to-east):
a. Display the west 4MD-xx.x card in card view.
b. Click the Provisioning > Optical Chn > Parameters tabs.
c. Verify that the Power value on the CHAN TX port is higher than the default no-power value of
–35 dBm.
Step 7 Verify the east 4MD-xx.x (west-to-east):
a. Display the east 4MD-xx.x card in card view.
b. Click the Provisioning > Optical Chn > Parameters tabs.
c. Change the Admin State of the CHAN RX port to OOS,MT (ANSI) or Locked,maintenance
(ETSI) for the channel related to the wavelength selected on the tunable laser.
d. Verify that the Power value of the CHAN RX port reaches the provisioned setpoint (VOA Power
Ref).
Step 8 Return to your originating procedure (NTP).
DLP-G93 Verify Add and Drop Connections on an OADM Node with OSCM Cards
Note In this task, you will verify add and drop connections in the following order: east-to-west add and
west-to-east drop, Steps 1 through 15; west-to-east add and east-to-west drop, Steps 16 through 17.
Step 1 Based on the Cisco MetroPlanner site configuration file, tune the tunable laser or TXP_MR_2.5G card
to a wavelength (belonging to the 100-GHz ITU-T grid) of the channel running on the first add path of
the first west AD-xC-xx.x or west 4MD-xx.x card on the east-to-west direction. Refer to the tunable laser
manufacturer’s documentation or the “DLP-G268 Provision TXP_MR_2.5G Cards for Acceptance
Testing” task on page 4-4.
Step 2 Connect the tunable laser transmitter or the TXP_MR_2.5G card DWDM TX port to the corresponding
15xx.x RX port (on the card front panel) of the west AD-xC-xx.x or 4MD-xx.x card.
Step 3 Verify the west AD-xC-xx.x or 4MD-xx.x (east-to-west):
a. Display the west AD-xC-xx.x or 4MD-xx.x card in card view.
Purpose This task verifies the add and drop channel connections for an OADM node
with OSCM cards installed.
Tools/Equipment A tunable laser or eight TXP_MR_2.5G cards covering the 32 C-band
wavelengths (see Table 4-1 on page 4-4)
Prerequisite Procedures DLP-G46 Log into CTC, page 2-25
Required/As Needed As needed
Onsite/Remote Onsite
Security Level Superuser
