Cisco ONS 15454 DWDM User Manual

17-36
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.3.2 View and Provision ANS Parameters
The ANS parameters that appear in the WDM-ANS > Provisioning subtab depend on the node type.
Table 17-4 shows the DWDN node types and their ANS parameters.
Table 17-4 ANS Parameters By Node Type
Node Type Parameter Group Parameters
Hub Network Network Type
Span Loss East and West Expected Span Loss
Amplifier Tx East and West Side Transmit Amplifier Working Mode
East and West Side Transmit Amplifier Channel Power
East and West Side Transmit Amplifier Gain
East and West Side Transmit Amplifier Tilt
Amplifier Rx East and West Side Receive Amplifier Working Mode
East and West Side Receive Amplifier Channel Power
East and West Side Receive Amplifier Gain
East and West Side Receive Amplifier Tilt
Thresholds Tx East and West Side Fiber Stage Input Threshold
Thresholds Rx East and West Side Osc Los Threshold
East and West Side Channel Los Threshold
East and West Side Receive Amplifier Input Power Fail
Power East and West Side Add and Drop Input Power
East and West Side Add and Drop Output Power
East and West Side Add and Drop By-Pass Power
East and West Side Channel (n) Drop Power

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
