Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.3.2 View and Provision ANS Parameters
Terminal Network Network Type
Span Loss East or West Expected Span Loss
Amplifier Tx East or West Side Transmit Amplifier Working Mode
East or West Side Transmit Amplifier Channel Power
East or West Side Transmit Amplifier Gain
East or West Side Transmit Amplifier Tilt
Amplifier Rx East or West Side Receive Amplifier Working Mode
East or West Side Receive Amplifier Channel Power
East or West Side Receive Amplifier Gain
East or West Side Receive Amplifier Tilt
Thresholds Tx East or West Side Fiber Stage Input Threshold
Thresholds Rx East or West Side Osc Los Threshold
East or West Side Channel Los Threshold
East or West Side Receive Amplifier Input Power Fail
Power East or West Side Add and Drop Input Power
East or West Side Add and Drop Output Power
East or West Side Channel (n) Drop Power (n = 1-32)
Flexible Channel
Count Terminal
Network Network Type
Span Loss East and West Expected Span Loss
Amplifier Tx East and West Side Transmit Amplifier Working Mode
East and West Side Transmit Amplifier Channel Power
East and West Side Transmit Amplifier Gain
East and West Side Transmit Amplifier Tilt
Amplifier Rx East and West Side Receive Amplifier Working Mode
East and West Side Receive Amplifier Channel Power
East and West Side Receive Amplifier Gain
East and West Side Receive Amplifier Tilt
Thresholds Tx East and West Side Fiber Stage Input Threshold
Thresholds Rx East and West Side Osc Los Threshold
East and West Side Channel Los Threshold
East and West Side Receive Amplifier Input Power Fail
Power East and West Side Add and Drop Input Power
East and West Side Add and Drop Output Power
East and West Side Band (n) Drop Power (n = 1-8)
Table 17-4 ANS Parameters By Node Type (continued)
Node Type Parameter Group Parameters
