Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 17 Node Reference
17.3.2 View and Provision ANS Parameters
root +/– East +/– Receiving +/– Power East Side Add and Drop Input Power
East Side Add and Drop Drop Power
East Side Band n Drop Power (n = 1-8)
East Side Channel n Drop Power East (n = 1-32)
root +/– East +/– Receiving +/– Thresholds East Side OSC LOS Threshold
East Side Channel LOS Threshold
East Side Rx Amplifier In Power Fail Th
root +/– East +/– Transmitting +/– Amplifier East Side Tx Amplifier Working Mode
East Side Tx Amplifier Ch Power
East Side Tx Amplifier Gain
East Side Tx Amplifier Tilt
root +/– East +/– Transmitting +/– Power East Side Add and Drop Output Power
East Side Add and Drop By-Pass Power
root +/– East +/– Transmitting +/– Thresholds East Side Fiber Stage Input Threshold
root +/– West +/– Receiving West Side Rx Max Expected Span Loss
West Side Rx Min Expected Span Loss
root +/– West +/– Receiving +/– Amplifier West Side Rx Amplifier Working Mode
West Side Rx Amplifier Ch Power
West Side Rx Amplifier Gain
West Side Rx Amplifier Tilt
root +/– West +/– Receiving +/– Power West Side Add and Drop Input Power
West Side Add and Drop Drop Power
West Side Band n Drop Power (n = 1-8)
West Side Channel n Drop Power (n = 1-32)
root +/– West +/– Receiving +/– Thresholds West Side OSC LOS Threshold
West Side Channel LOS Threshold
West Side Rx Amplifier In Power Fail Th
root +/– West +/– Transmitting +/– Amplifier West Side Tx Amplifier Working Mode
West Side Tx Amplifier Ch Power
West Side Tx Amplifier Gain
West Side Tx Amplifier Tilt
root +/– East +/– Transmitting +/– Power West Side Add and Drop Output Power
West Side Add and Drop By-Pass Power
root +/– West +/– Transmitting +/– Thresholds West Side Fiber Stage Input Threshold
Table 17-3 ANS-WDM > Provisioning Subtab Parameters (continued)
Tree Element Parameters
To Next Page
