Cisco ONS 15454 DWDM - Page 399

5-61
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
September 2005
Chapter 5 Provision Transponder and Muxponder Cards
DLP-G306 Provision the TXP_MR_2.5G and TXPP_MR_2.5G Cards Client Port Alarm and TCA Thresholds
Step 7 Click Apply.
Step 8 Return to your originating procedure (NTP).
PASS-THRU 2R MODE (not specified) Service Dependent
FC1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FC2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–18 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FICON1G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
FICON2G 15454-SFP-GEFC-SX
15454E-SFP-GEFC-S
–20 3 –13 –1
15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
ETR_CLO 15454-SFP-200
15454E-SFP-200
–20 3 –13 –1
ISC compat 15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
ISC peer 15454-SFP-GE+-LX
15454E-SFP-GE+-LX
–23 0 –13 0
Table 5-36 TXP_MR_2.5G and TXPP_MR_2.5G Card Client Interface Alarm Thresholds
Port Type
(by CTC)
Pluggable Port Module
(SFP)
Alarm RX
Power Low
Alarm RX
Power High
Alarm TX
Power Low
Alarm TX
Power High
