Appendix C DWDM Administrative and Service States
C.3.5 Transponder/Muxponder Card Service State Transitions
OOS-AUMA,MEA & UAS (ANSI)
Locked-disabled,mismatchOfEquipment
& unassigned (ETSI)
Pull the card. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled
(ETSI)
Provision the card. OOS-AU,MEA (ANSI)
Locked-disabled,mismatchOfEquipment
(ETSI)
OOS-AUMA,MT & SWDL (ANSI)
Locked-disabled,maintenance &
softwareDownload (ETSI)
Restart completed. OOS-MA,MT (ANSI)
Locked-enabled,maintenance (ETSI)
Pull the card. OOS-AUMA,MT & UEQ (ANSI)
Locked-disabled,maintenance & notInstalled
(ETSI)
OOS-AUMA,MT & UEQ (ANSI)
Locked-disabled,maintenance &
notInstalled (ETSI)
Change the administrative state
to IS (ANSI) or Unlocked
(ETSI).
OOS-AU,UEQ (ANSI)
Locked-disabled,notInstalled (ETSI)
Insert a valid card. OOS-AUMA,MT & SWDL (ANSI)
Locked-disabled,maintenance &
softwareDownload (ETSI)
Insert an invalid card. OOS-AUMA,MEA & MT (ANSI)
Locked-disabled,mismatchOfEquipment &
maintenance (ETSI)
Delete the card. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled
(ETSI)
OOS-AUMA,UAS (ANSI)
Locked-disabled,unassigned (ETSI)
Pull the card. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled
(ETSI)
Provision an invalid card. OOS-AU,MEA (ANSI)
Locked-disabled,mismatchOfEquipment
(ETSI)
Provision a valid card. OOS-AU,SWDL (ANSI)
Locked-disabled,softwareDownload (ETSI)
OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned &
notInstalled (ETSI)
Insert a valid card. OOS-AU,SWDL (ANSI)
Locked-disabled,softwareDownload (ETSI)
Insert an invalid card. OOS-AUMA,MEA & UAS (ANSI)
Locked-disabled,mismatchOfEquipment &
unassigned (ETSI)
Preprovision a card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Table C-8 ONS 15454 Transponder/Muxponder Card Service State Transitions (continued)
Current Service State Action Next Service State
