Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Chapter 1 Install the Shelf and Common Control Cards
NTP-G7 Install the Power and Ground
Warning
This product requires short-circuit (overcurrent) protection, to be provided as part of the building
installation. Install only in accordance with national and local wiring regulations.
Statement 1045
Warning
A readily accessible two-poled disconnect device must be incorporated in the fixed wiring.
Statement
1022
Warning
This unit might have more than one power supply connection. All connections must be removed to
de-energize the unit.
Statement 1028
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Step 1 Verify that the correct fuse and alarm panel is installed in the top mounting space:
• (ETSI only.) Verify that a 100-A fuse panel (30-A fuse per shelf minimum) is installed. If not, install
one according to manufacturer’s instructions.
• (ANSI only.) If you have the 15454-SA-ANSI or 15454-SA-HD shelf, a 100-A fuse panel (30-A fuse
per shelf minimum) should be installed. If not, install one according to manufacturer’s instructions.
• (ANSI only.) If you have the 15454-SA-NEBS3 shelf, a standard 80-A fuse panel (20-A fuse per
shelf minimum) should be installed. If not, install one according to manufacturer’s instructions.
Step 2 Depending on your type of shelf, complete the “DLP-G15 Connect the Office Ground to the
ONS 15454 ETSI” task on page 1-32 or the “DLP-G16 Connect the Office Ground to the
ONS 15454 ANSI” task on page 1-34.
Step 3 Depending on your shelf, complete the “DLP-G17 Connect Office Power to the ONS 15454 ETSI” task
on page 1-35 or the “DLP-G18 Connect Office Power to the ONS 15454 ANSI” task on page 1-37.
Step 4 Complete the “DLP-G19 Turn On and Verify Office Power” task on page 1-39.
Step 5 Continue with the “NTP-G8 Install the Fan-Tray Assembly” procedure on page 1-40.
Stop. You have completed this procedure.
