D-15
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Appendix D Network Element Defaults
D.2.1 ANSI Card Default Settings
MXP-MR-2_5G.opticalthresholds.client.warning.1day.HighTxPow
er
2.5 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.client.warning.1day.LowRxPowe
r
-20.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.client.warning.1day.LowTxPowe
r
-7.5 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighLaserBias 98.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighRxPower -8.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.alarm.HighTxPower 30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.alarm.LowRxPower -25.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.alarm.LowTxPower -40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighLaser
Bias
95.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighRxPo
wer
-7.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighTxPo
wer
30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowRxPo
wer
-24.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowTxPow
er
-40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighLaserBi
as
96.0 (%) 0.0, 0.1, 0.2 .. 100.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighRxPow
er
-7.3 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighTxPowe
r
30.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowRxPowe
r
-24.7 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
MXP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowTxPowe
r
-40.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
MXP-MR-2_5G.pmthresholds.trunk.line.farend.15min.CV 21260 (B2 count) 0–2212200
MXP-MR-2_5G.pmthresholds.trunk.line.farend.15min.ES 87 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.line.farend.15min.FC 10 (count) 0–72
MXP-MR-2_5G.pmthresholds.trunk.line.farend.15min.SES 1 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.line.farend.15min.UAS 3 (seconds) 0–900
MXP-MR-2_5G.pmthresholds.trunk.line.farend.1day.CV 212600 (B2 count) 0–212371200
Table D-3 MXP_MR_2.5G Card Default Settings (ANSI) (continued)
Default Name Default Value Default Domain
