Cisco ONS 15454 DWDM - Page 1198

D-98
Cisco ONS 15454 DWDM Installation and Operations Guide, R6.0
August 2005
Appendix D Network Element Defaults
D.3.1 ETSI Card Default Settings
TXPP-MR-2_5G.opticalthresholds.client.alarm.HighTxPower 3.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.client.alarm.LowRxPower -21.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.opticalthresholds.client.alarm.LowTxPower -15.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
TXPP-MR-2_5G.opticalthresholds.client.warning.15min.HighLaserBias 81.0 (%) 0.0, 0.1, 0.2 .. 100.0
TXPP-MR-2_5G.opticalthresholds.client.warning.15min.HighRxPower 2.0 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.client.warning.15min.HighTxPower 2.0 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.client.warning.15min.LowRxPower -20.0 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.opticalthresholds.client.warning.15min.LowTxPower -7.0 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
TXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighLaserBias 85.5 (%) 0.0, 0.1, 0.2 .. 100.0
TXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighRxPower 2.5 (dBm) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.client.warning.1day.HighTxPower 2.5 (dBm) LowTxPower, LowTxPower +
0.1, LowTxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.client.warning.1day.LowRxPower -20.5 (dBm) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.opticalthresholds.client.warning.1day.LowTxPower -7.5 (dBm) -40.0, -39.9, -39.8 ..
HighTxPower
TXPP-MR-2_5G.opticalthresholds.trunk.alarm.HighLaserBias 98.0 (%) 0.0, 0.1, 0.2 .. 100.0
TXPP-MR-2_5G.opticalthresholds.trunk.alarm.HighRxPower -8.0 (dBrn) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.trunk.alarm.LowRxPower -25.0 (dBrn) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighLaserBias 95.0 (%) 0.0, 0.1, 0.2 .. 100.0
TXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.HighRxPower -7.5 (dBrn) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.trunk.warning.15min.LowRxPower -24.5 (dBrn) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighLaserBias 96.0 (%) 0.0, 0.1, 0.2 .. 100.0
TXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.HighRxPower -7.3 (dBrn) LowRxPower, LowRxPower +
0.1, LowRxPower + 0.2 .. 30.0
TXPP-MR-2_5G.opticalthresholds.trunk.warning.1day.LowRxPower -24.7 (dBrn) -40.0, -39.9, -39.8 ..
HighRxPower
TXPP-MR-2_5G.otn.fecthresholds.1gethernet.15min.BitErrorsCorrected 112500
(count)
0–9033621811200
Table D-20 TXPP-MR-2.5G Card Default Settings (ETSI) (continued)
Default Name Default Value Default Domain
