RUGGEDCOM ROX II
CLI User Guide
Chapter 4
Device Management
Viewing Module Information 57
show chassis hardware slot-hardware
A table or list similar to the following example appears:
ruggedcom# show chassis hardware slot-hardware | tab
SLOT ORDER FIELD DETECTED MODULE
--------------------------------------------------------------------------------
pm1 XX none
lm1 XX none
lm2 XX none
lm3 16TX01 16x 10/100TX RJ45
cm CM01 RX5000 Control Module
sm SM02 SM 8 Gigabit Layer 2 w/ 2x 10/100/1000TX RJ45
lm4 6GK6050-0AL20-0CU0 8x 100FX SFP
lm5 XX none
lm6 XX none
pm2 HI Power 88-300VDC or 85-264VAC w/ screw terminal block
main RX5000 RX5000 Backplane
em none
This table or list provides the following information:
Parameter Description
slot Synopsis:  { { --- }{ pm1, pm2, main }{ sm, lm1, lm2, lm3, lm4, lm5, lm6, swport, eth,
serport, celport, wlanport }{ cm, em }{ trnk } }
The slot name, as marked on the silkscreen across the top of the chassis.
order-field Synopsis:  A string 1 to 25 characters long
The order code of the chassis as derived from the current hardware configuration.
This parameter is mandatory.
detected-module Synopsis:  A string 1 to 60 characters long
The installed module's type specifier.
This parameter is mandatory.
Section4.2.2
Viewing Module Information
To view information about the modules installed in the device, type:
show chassis info slot-info
A table or list similar to the following example appears:
ruggedcom# show chassis info slot-info | tab
SLOT DETECTED MODULE BootLoader FPGA
---------------------------------------------------------------------------
lm3 16x 10/100TX RJ45 ---- ----
cm RX5000 Control Module 1:2010.09RR24 10-14
sm SM 8 Gigabit Layer 2 w/ 2x 10/100/1000TX RJ45 ---- ----
lm4 8x 100FX SFP ---- ----
This table or list provides the following information:
Parameter Description
slot Synopsis:  { { --- }{ pm1, pm2, main }{ sm, lm1, lm2, lm3, lm4, lm5, lm6, swport, eth,
serport, celport, wlanport }{ cm, em }{ trnk } }
The slot name, as marked on the silkscreen across the top of the chassis.
