Siemens RUGGEDCOM ROX II User Manual

Chapter 16
Traffic Control and Classification
RUGGEDCOM ROX II
CLI User Guide
708 Adding a QoS Map
• For Virtual Switches
show running-config interface virtualswitch id vlan vlan-id qosmap
Where:
▫ id is the ID of the virtual switch
▫ vlan-id is the ID given to the VLAN
If QoS maps have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config interface virtualswitch vlan 100 qosmap
interface
virtualswitch 1
vlan 100
qosmap 2
ingress 10
!
!
!
!
If no QoS maps have been configured, add maps as needed. For more information, refer to Section16.2.7.2,
“Adding a QoS Map”.
Section16.2.7.2
Adding a QoS Map
To add a QoS map for a VLAN connection, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the QoS map by typing:
• For Switched Ethernet Ports
switch vlans all-vlans id qosmap priority
Where:
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
• For Routable-Only Ethernet Ports
interface eth slot port vlan id qosmap priority
Where:
▫ slot is the name of the module location
▫ port is the port number (or a list of ports, if aggregated in a port trunk) for the module
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
• For Virtual Switches
interface virtualswitch id vlan vlan-id qosmap priority
Where:
▫ id is the ID of the virtual switch
▫ vlan-id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
