Siemens RUGGEDCOM ROX II User Manual

Chapter 10
Serial Server
RUGGEDCOM ROX II
CLI User Guide
342
Example: Serial Interfaces Configured as a Source for
Multicast Streams
For more information, refer to Section10.8.2, “Adding a Local Host Interface”
6. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
7. Verify the configuration by typing the following:
traceserial
Final Configuration Example
ser-1-1 Configuration
serial lm1 1
no alias
protocols rawsocket
setrawsocket local-port 5001
setrawsocket transport udp
setrawsocket local-host 232.1.1.1
interface switch.0010
ser-1-2 Configuration
serial lm1 2
no alias
protocols rawsocket
setrawsocket local-port 6001
setrawsocket transport udp
setrawsocket local-host 232.2.2.2
interface switch.0020
Section10.4.4
Example: Serial Interfaces Configured as a Source for
Multicast Streams
This configuration example shows ser-1-1 receiving data on the wire from S1, then creating multiple raw socket
remote host interfaces to send the data to both interfaces switch.0010 and switch.0020. This data is then
packetized as multicast packets and sent to destination group 232.1.1.1 and destination UDP port 5001.
IMPORTANT!
The values shown are specific to the provided topology. Actual values can vary based on the user's
configuration.
