Chapter 13
Unicast and Multicast Routing
RUGGEDCOM ROX II
CLI User Guide
468 Tracking Commands
Section13.7.4.2
Tracking Commands
Network commands can be tracked using event trackers configured under global» tracking. For more
information about event trackers, refer to Section13.5, “Managing Event Trackers”.
A network command is activated based on the event tracker's state. The apply-when parameter determines
when the command is activated. For example, if the apply-when parameter is set to down, the network
command becomes active (thereby advertising the network to a router's RIP peers) when the tracked target is
unavailable.
To track a command for a RIP network, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to routing» rip» distribute-prefix-list» {direction} {interface}» track, where {direction} is
the direction (incoming or outgoing) in which to filter routing updates and {interface} is the name of the
interface.
3. Configure the following parameter(s) as required:
Parameter Description
event { event } Synopsis: A string
Selects an event to track. The distribute-prefix-list is applied only when the tracked event
is in the UP state.
This parameter is mandatory.
apply-when { apply-when } Synopsis: { up, down }
Default: up
Applies the distribute-prefix-list when the tracked event goes UP or DOWN.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section13.7.5
Managing Network IP Addresses
This section describes how to manage IP addresses for RIP networks.
CONTENTS
• Section13.7.5.1, “Viewing a List of Network IP Addresses”
• Section13.7.5.2, “Adding a Network IP Address”
• Section13.7.5.3, “Deleting a Network IP Address”
Section13.7.5.1
Viewing a List of Network IP Addresses
To view a list of IP addresses configured for a RIP network, type:
show running-config routing rip network ip
If addresses have been configured, a table or list similar to the following example appears:
