Chapter 14
Network Redundancy
RUGGEDCOM ROX II
CLI User Guide
618 Adding a Dedicated Link
!
!
If no dedicated links have been configured, add dedicated links as needed. For more information, refer to
Section14.1.10.4, “Adding a Dedicated Link”.
Section14.1.10.4
Adding a Dedicated Link
To add a dedicated link, do the following:
1. Make sure the CLI is in Configuration mode.
NOTE
RUGGEDCOM ROX II supports up to four dedicated links.
2. Add a dedicated link by typing:
services conn-sync dedicated-link name
Where name is the name of the dedicated link.
3. Configure the following parameter(s) as required:
Parameter Description
interface { interface } Synopsis:  A string
The interface name of the dedicated link.
ip { ip } Synopsis:  A string 7 to 15 characters long or a string 6 to 40 characters long
The IPv4 or IPv6 address of the dedicated link interface.
mcast-ip { mcast-ip } Synopsis:  A string 7 to 15 characters long or a string 7 to 39 characters long
Default:  225.0.0.50
The destination IPv4 or IPv6 multicast address of the dedicated link.
group { group } Synopsis:  A 16-bit unsigned integer between 1 and 65535
Default:  3780
The multicast group ID of the cluster.
send-buffer { send-buffer } Synopsis:  A 32-bit unsigned integer between 64 and 2560
Default:  1220
The sending socket buffer size in kB.
recv-buffer { recv-buffer } Synopsis:  A 32-bit unsigned integer between 64 and 2560
Default:  1220
The receiving socket buffer size in kB.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section14.1.10.5
Deleting a Dedicated Link
To delete a dedicated link, do the following:
