Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 14
Network Redundancy
Adding a Link Failover Parameter 623
link-failover switch.0001
enabled
backup fe-1-1
transfer-default-route
backup-gateway 192.168.1.2
!
backup te1-2-1c01ppp
priority second
transfer-default-route
!
target 10.10.10.10
!
!
!
If no parameters have been configured, add parameters as needed. For more information, refer to
Section14.2.3.2, “Adding a Link Failover Parameter”.
Section14.2.3.2
Adding a Link Failover Parameter
To add a link failover parameter, do the following:
NOTE
The link failover feature can only be configured on a routable interface. For the link failover feature to
be used on a switched port, another VLAN must be configured (for example, switch.0002) to logically
differentiate the switched port from the default PVID VLAN 1 (switch.0001).
1. Make sure the CLI is in Configuration mode.
2. Add the parameter by typing:
services link-failover interface
Where:
• interface is the name of the interface
3. Configure the following parameter(s) as required:
Parameter Description
enabled Enables this link backup.
ping-timeout { ping-timeout } Synopsis:  A 32-bit signed integer between 1 and 65536
Default:  2
The time interval, in seconds, before immediately retrying a ping.
ping-interval { ping-interval } Synopsis:  A 32-bit signed integer between 0 and 65536
Default:  60
The time interval, in seconds, between ping tests.
ping-retry { ping-retry } Synopsis:  A 32-bit signed integer between 0 and 65536
Default:  3
The number of ping retries before constructing a path failure.
start-delay { start-delay } Synopsis:  A 32-bit signed integer between 0 and 65536
Default:  180
The delay time, in seconds, when first starting link failover.
main-down-timeout { main-down-
timeout }
Synopsis:  A 32-bit signed integer between 0 and 65536
Default:  60
