Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Viewing the Status of the Forwarding Table 543
2.2.2.2/32 18 192.168.10.1 imp-null
3.3.3.3/32 imp-null
4.4.4.4/32 imp-null
5.5.5.5/32 19 192.168.20.2 imp-null
6.6.6.6/32 20 192.168.20.2 imp-null
10.200.16.0/20 16
172.30.128.0/19 imp-null
192.168.10.0/24 imp-null
192.168.20.0/24 imp-null
192.168.100.0/24 21 192.168.10.1 imp-null
192.168.200.0/24 22 192.168.20.2 imp-null
This table provides the following information:
Parameter Description
prefix Synopsis:  A string
The destination address prefix.
local-label Synopsis:  A string
The incoming (local) label.
next-hop Synopsis:  A string
The destination next hop router.
remote-label Synopsis:  A string
The remote label
Section13.10.2
Viewing the Status of the Forwarding Table
To view the status of the forwarding table on the device, type:
show mpls status forwarding-table
A table or list similar to the following example appears:
ruggedcom# show mpls status forwarding-table
LOCAL OUTGOING OUTGOING
LABEL LABEL PREFIX INTERFACE NEXT HOP UPTIME
------------------------------------------------------------------------
17 Pop 1.1.1.1/32 switch.0010 192.168.10.1 01:04:31
18 Pop 2.2.2.2/32 switch.0010 192.168.10.1 01:04:31
19 Pop 5.5.5.5/32 switch.0020 192.168.20.2 01:04:33
20 Pop 6.6.6.6/32 switch.0020 192.168.20.2 01:04:33
21 Pop 192.168.100.0/24 switch.0010 192.168.10.1 01:04:31
22 Pop 192.168.200.0/24 switch.0020 192.168.20.2 01:04:33
This table or list provides the following information:
Parameter Description
local-label Synopsis:  A string
The incoming (local) label
outgoing-label Synopsis:  A string
The outgoing (remote) label.
prefix Synopsis:  A string
The destination address prefix.
