Chapter 6

Security

RUGGEDCOM ROX II

CLI User Guide

190 Configuring Netfilter

To configure the firewall for a VPN in a DMZ, do the following:

1. Make sure a basic firewall has been configured. For more information about configuring a firewall, refer to

Section6.9.3, “Adding a Firewall”.

2. Make sure a zone called dmz exists. For more information about managing zones, refer to Section6.9.9,

“Managing Zones”.

3. Configure rules with the following parameter settings for the UDP, Authentication Header (AH) and

Encapsulation Security Payload (ESP) protocols:

NOTE

The IPsec protocol operations on UDP port 500, using protocols Authentication Header (AH) and

Encapsulation Security Payload (ESP) protocols. The firewall must be configured to accept this

traffic in order to allow the IPsec protocol.

Action Source-Zone Destination-Zone Protocol Dest-Port

Accept Net dmz Ah —

Accept Net dmz Esp —

Accept Net dmz UDP 500

Accept dmz Net Ah —

Accept dmz Net Esp —

Accept dmz Net Udp 500

For more information about configuring rules, refer to Section6.9.15, “Managing Rules”.

Section6.9.8

Configuring Netfilter

To configure Netfilter, do the following:

1. Make sure the CLI is in Configuration mode.

2. Set the time in seconds (s) a stale TCP connection can reside in the connection tracking table by typing:

admin system tcp-est-conn-track-timeout value

Where value is a number between 300 and 432000. The default value is 432000 s, or five days.

3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.

Section6.9.9

Managing Zones

A network zone is a collection of interfaces for which forwarding decisions are made. Common zones include:

Zone Description

Net The Internet

Loc The local network
