Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Viewing a List of Static Labels 547
If no static label binding has been configured, configure binding as needed. For more information about
configuring static-binding, refer to Section13.10.5.3, “Adding a Static Label”.
Section13.10.5.2
Viewing a List of Static Labels
To view a list of static labels, type:
show running-config mpls static-mpls binding [ ipv4 | ipv6 ]
If static labels have been configured, a list similar to the following example appears:
ruggedcom# show running-config mpls static-mpls binding ipv4
mpls
static-mpls
binding
ipv4
dest-address 192.168.52.52/32
next-hop 192.168.10.2
out-label 16
!
!
!
!
!
If no static labels have been configured, add labels as needed. For more information about adding static labels,
refer to Section13.10.5.3, “Adding a Static Label”.
Section13.10.5.3
Adding a Static Label
To add a static label, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add a static label by typing:
mpls static-mpls binding [ ipv4 | ipv6 ] dest-address address
Where:
• address is the destination address and prefix.
3. Configure the following parameter(s) as required:
Parameter Description
in-label { in-label } Synopsis:  A 32-bit unsigned integer between 16 and 1048575
The incoming label: integer 16 -> 1048575.
next-hop { next-hop } Synopsis:  A string 7 to 15 characters long
The IP address for the destination next-hop router.
out-label { out-label } Synopsis:  { explicit-null, implicit-null } or a 32-bit unsigned integer between 16 and
1048575
The outgoing label:
• implicit null - The label has a value of 3, meaning the penultimate (next-to-last) router
performs a pop operation and forwards the remainder of the packet to the egress
