RUGGEDCOM ROX II
CLI User Guide
Chapter 10
Serial Server
Adding a Device Address Table 337
Where:
• slot/port is the slot name and port number of the serial port
If Device Address tables have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config interface serial protocols dnp setdnp device-table
interface
serial lm3 1
protocols dnp
setdnp device-table 12
remote-ip 172.30.130.2
remote-device
!
!
!
!
If no Device Address tables have been configured, add tables as needed. For more information, refer to
Section10.3.2, “Adding a Device Address Table”.
Section10.3.2
Adding a Device Address Table
To add a Device Address table for a serial port using the DNP protocol, do the following:
1. Make sure the CLI is in Configuration mode.
2.
interface serial slot port protocols dnp setdnp device-table address
Where:
• slot is the name of the module location.
• port is the port number (or a list of ports, if aggregated in a port trunk) for the module.
• address is the local or remote DNP device address. The address may be that of a DNP device connected to
a local serial port or one available via the serial port of a remote IP host.
3. Configure the following parameter(s) as required:
Parameter Description
remote-ip { remote-ip } Synopsis: A string 7 to 15 characters long or a string 6 to 40 characters long
The IP address of the remote host that provides a connection to the DNP device with
the configured address. Leave this field empty to forward DNP messages that match the
configured address to the local serial port.
remote-device Enables forwarding of DNP messages that match the device address to the remote IP.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section10.3.3
Deleting a Device Address Table
To delete a Device Address table, do the following:
1. Make sure the CLI is in Configuration mode.
2. Delete the Device Address Table by typing:
