Siemens RUGGEDCOM ROX II User Manual

RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Managing VRF Definitions 561
Section13.11.5
Managing VRF Definitions
VRF definitions represent individual Customer Edge (CE) routers in the VRF topology. RUGGEDCOM ROX II supports
up to eight definitions in total, each composed of a unique VRF name, an optional description and a Route
Distinguisher (RD). The Route Distinguisher is an 8 octet field typically made up of an AS number or IP address
followed by a colon (:) and the site ID (e.g. 6500:20 or 172.20.120.12:10). When prefixed to the IPv4 address of
the associated interface, it uniquely identifies each IP packet, allowing the Provider Edge (PE) to determine which
VPN tunnel the packet belongs to.
Each VRF definition can also be associated with one or more route targets.
CONTENTS
• Section13.11.5.1, “Viewing a List of VRF Definitions”
• Section13.11.5.2, “Adding a VRF Definition”
• Section13.11.5.3, “Deleting a VRF Definition”
Section13.11.5.1
Viewing a List of VRF Definitions
To view a list of VRF definitions, type:
show running-config global vrf
If definitions have been configured, a table or list similar to the following example appears:
show running-config global vrf | tab
global
vrf
definition
VRF VRF EXPORT IMPORT BOTH
NAME DESCRIPTION RD COMMUNITY COMMUNITY COMMUNITY
-----------------------------------------------------------
vrf1 Site A 100:1
100:2
vrf2 Site B 100:2
100:1
!
!
If no VRF definitions have been configured, add definitions as needed. For more information, refer to
Section13.11.5.2, “Adding a VRF Definition”.
Section13.11.5.2
Adding a VRF Definition
To add a VRF definition, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the definition by typing:
global vrf definition name
