RUGGEDCOM ROX II

CLI User Guide

Chapter 13

Unicast and Multicast Routing

Viewing the Status of the Link-State Database 445

Parameter Description

System ID The system ID.

Interface The name of the interface.

L The level. Possible levels are 1, 2 and 3, where 3 represents levels 1 and 2.

State Adjacency state.

Holdtime The remaining hold time in seconds.

SNPA The MAC address of the Sub-Network Point of Attachment (SNPA).

Section13.6.4

Viewing the Status of the Link-State Database

To view the basic status of the link-state database for the IS-IS network, do the following:

1. Make sure IS-IS is configured. For more information, refer to Section13.6.2, “Configuring IS-IS”.

2. Display the basic status by typing:

routing status isis isis-database-status

Or display a more detailed status by typing:

routing status isis isis-database-detail-status

If IS-IS routes have been configured, a list similar to the following example appears:

ruggedcom# routing status isis isis-database-status

isis-database-status

Area area1:

IS-IS Level-1 link-state database:

LSP ID PduLen SeqNumber Chksum Holdtime ATT/P/OL

R1.00-00 * 75 0x00000015 0xe43a 1129 0/0/0

1 LSPs

IS-IS Level-2 link-state database:

LSP ID PduLen SeqNumber Chksum Holdtime ATT/P/OL

Spirent-.00-00 121 0x0000000f 0xd5e6 871 0/0/0

R1.00-00 * 75 0x00000015 0xe636 1031 0/0/0

Spirent-right.00-00 1465 0x0000000f 0x3d65 871 0/0/0

Spirent-right.00-01 295 0x0000000f 0x6a0d 872 0/0/0

Spirent-right.00-00 1465 0x0000000f 0x4638 872 0/0/0

Spirent-right.00-01 287 0x0000000f 0x54d0 872 0/0/0

Spirent-right.00-00 1462 0x0000000f 0x6528 872 0/0/0
