RUGGEDCOM ROX II
CLI User Guide
Chapter 10
Serial Server
Adding a Serial Port Protocol 333
If protocols have been configured, a table or list similar to the following example appears:
ruggedcom# show interfaces serial port protocol
IFNAME PROTOCOL
-------------------
ser-3-1 none
ser-3-2 none
ser-3-3 none
ser-3-4 none
ser-3-5 none
ser-3-6 none
If no serial port protocols have been configured, add protocols as needed. For more information, refer to
Section10.2.3, “Adding a Serial Port Protocol”.
Section10.2.3
Adding a Serial Port Protocol
To add a serial port protocol, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the protocol by typing:
interface serial slot port protocols protocol
Where:
• slot is the name of the module location.
• port is the port number (or a list of ports, if aggregated in a port trunk) for the module.
• protocol is the protocol type. Options include dnp, tcpmodbus, rawsocket and vmserial.
3. If dnp, tcpmodbus, or rawsocket was selected, configure the protocol.
• For information about configuring a DNP protocol, refer to Section10.2.4, “Configuring the DNP Protocol”.
• For information about configuring a Modbus TCP protocol, refer to Section10.2.5, “Configuring the
Modbus TCP Protocol”.
• For information about configuring a raw socket protocol, refer to Section10.2.6, “Configuring the Raw
Socket Protocol”.
4. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section10.2.4
Configuring the DNP Protocol
To configure the DNP protocol for a serial port, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to interface» serial» {interface}» protocols» dnp» setdnp, where {interface} is the serial port.
3. Configure the following parameter(s) as required:
Parameter Description
address-learning { address-learning } Synopsis:  A string 1 to 15 characters long
The interface to learn the RTU address from.
