Siemens RUGGEDCOM ROX II User Manual

Chapter 16
Traffic Control and Classification
RUGGEDCOM ROX II
CLI User Guide
710 Managing Egress Markers for QoS Maps
Section16.2.8
Managing Egress Markers for QoS Maps
Egress markers for QoS maps are used to assign priority to traffic that shares the same mark as one of the egress
marks configured for the device.
CONTENTS
• Section16.2.8.1, “Viewing a List of Egress Marks”
• Section16.2.8.2, “Adding an Egress Mark”
• Section16.2.8.3, “Deleting an Egress Mark”
Section16.2.8.1
Viewing a List of Egress Marks
To view a list of egress marks for a QoS map, type:
• For Switched Ethernet Ports
show running-config interface switch vlans all-vlans id qosmap priority egress
Where:
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
• For Routable-Only Ethernet Ports
show running-config interface eth slot port vlan id qosmap priority egress
Where:
▫ slot is the name of the module location
▫ port is the port number (or a list of ports, if aggregated in a port trunk) for the module
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
• For Virtual Switches
show running-config interface virtualswitch id vlan vlan-id qosmap priority egress
Where:
▫ slot is the name of the module location
▫ port is the port number (or a list of ports, if aggregated in a port trunk) for the module
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
If egress marks have been configured, a table or list similar to the following example appears:
show running-config interface virtualswitch vs1 vlan 100 qosmap 2 egress
interface
virtualswitch vs1
vlan 100
qosmap 2
egress 11
!
!
