Chapter 12
Tunneling and VPNs
RUGGEDCOM ROX II
CLI User Guide
408 Configuring Certificates and Keys
Section12.8.3
Configuring Certificates and Keys
To configure certificates and keys for IPsec Tunnels, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add a CA certificate and Certificate Revocation List (CRL). For more information, refer to Section6.8.4.3,
“Adding a CA Certificate and CRL”.
3. Add a private key. For more information, refer to Section6.8.5.2, “Adding a Private Key”.
4. Add a certificate. For more information, refer to Section6.8.7.3, “Adding a Certificate”.
5. Add a public key. For more information, refer to Section6.8.6.2, “Adding a Public Key”.
6. Navigate to tunnel» ipsec» connection» {connection}» {end}, where {connection} is the name of the
connection and {end} is the either the left (local router) or right (remote router) connection end.
7. Configure the system public key by typing:
tunnel ipsec connection connection [ left | right ] key type certificate
Where:
• connection is the name of the connection
8. Configure the system identifier by typing:
tunnel ipsec connection connection [ left | right ] identifier type from-certificate
Where:
• connection is the name of the connection
9. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section12.8.4
Viewing the IPsec Tunnel Status
To view the status of the IPsec tunnel, type:
1. Make sure the CLI is in Configuration mode.
2. Display the status by typing:
show ipsec status
A table or list similar to the following example appears:
status
========================================================
000 using kernel interface: netkey
000 interface lo/lo :1
000 interface lo/lo 127.0.0.1
000 interface vrf_gw0/vrf_gw0 169.254.0.1
000 interface switch.0001/switch.0001 192.168.0.2
000 interface switch.1000/switch.1000 172.30.151.38
000 %myid = (none)
000 debug none
000
000 virtual_private (%priv):
000 - allowed 0 subnets:
000 - disallowed 0 subnets:
