Chapter 16
Traffic Control and Classification
RUGGEDCOM ROX II
CLI User Guide
688 Configuring Port Mirroring
• Section16.1.3, “Managing Ingress Source Ports”
Section16.1.1
Configuring Port Mirroring
To configure port mirroring, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to switch» port-mirroring.
3. Configure port mirroring for a specific port by typing:
switch port-mirroring enabled target-slot slot target-port port egress-src egress ingress-src
ingress
Where:
• slot is the name of the module location
• port is the port number (or a list of ports, if aggregated in a port trunk)
• egress is the port number for the outgoing port
• ingress is the port number for the the incoming port
4. Add egress and ingress source ports. For more information, refer to Section16.1.2.2, “Adding an Egress
Source Port” and Section16.1.3.2, “Adding an Ingress Source Port”.
5. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section16.1.2
Managing Egress Source Ports
This section describes how to configure and manage egress source ports for port mirroring.
CONTENTS
• Section16.1.2.1, “Viewing a List of Egress Source Ports”
• Section16.1.2.2, “Adding an Egress Source Port”
• Section16.1.2.3, “Deleting an Egress Source Port”
Section16.1.2.1
Viewing a List of Egress Source Ports
To view a list of egress source port for port mirroring, type:
show running-config switch port-mirroring egress-src
If egress source ports have been configured, a table or list similar to the following example appears:
ruggedcom# show running-config switch port-mirroring egress-src
switch port-mirroring
egress-src lm1 1
!
