RUGGEDCOM ROX II
CLI User Guide
Chapter 16
Traffic Control and Classification
Adding an Egress Mark 711
!
!
!
If no egress marks have been configured, add egress marks as needed. For more information, refer to
Section16.2.8.2, “Adding an Egress Mark”.
Section16.2.8.2
Adding an Egress Mark
To add an egress mark for a QoS Map, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the QoS map by typing:
• For Switched Ethernet Ports
switch vlans all-vlans id qosmap priority egress mark
Where:
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
▫ mark is the value of the egress mark
• For Routable-Only Ethernet Ports
interface eth slot port vlan id qosmap priority egress mark
Where:
▫ slot is the name of the module location
▫ port is the port number (or a list of ports, if aggregated in a port trunk) for the module
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
▫ mark is the value of the egress mark
• For Virtual Switches
interface virtualswitch id vlan vlan-id qosmap priority egress mark
Where:
▫ slot is the name of the module location
▫ port is the port number (or a list of ports, if aggregated in a port trunk) for the module
▫ id is the ID given to the VLAN
▫ priority is the priority assigned to the QoS map
▫ mark is the value of the egress mark
3. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section16.2.8.3
Deleting an Egress Mark
To delete an egress mark for a QoS map, do the following:
