RUGGEDCOM ROX II
CLI User Guide
Chapter 8
Layer 2
Viewing the Status of a Switched Ethernet Port 273
Parameter Description
This parameter is mandatory.
out-pkts Synopsis:  A 32-bit unsigned integer
The number of transmitted good packets.
This parameter is mandatory.
error-pkts Synopsis:  A 32-bit unsigned integer
The number of any type of erroneous packets.
This parameter is mandatory.
Section8.1.4
Viewing the Status of a Switched Ethernet Port
To view the current status of a switched Ethernet port, type:
show interfaces switch slot port
Where:
• slot is the name of the module location (e.g. lm1)
• port is the port number for the switched Ethernet port
A table or list similar to the following example appears:
interfaces switch lm1 1
name ge-1-1
state up
media 1000T
speed 100M
duplex full
mtu 1500
mac 00:0a:dc:f6:c6:21
.
.
.
This table or list provides the following information:
Parameter Description
name Synopsis:  A string 1 to 10 characters long
A descriptive name that may be used to identify the device connected on that port.
This parameter is mandatory.
state Synopsis:  { not set, up, down, testing, unknown, dormant, notPresent, lowerLayerDown }
The port's link status.
This parameter is mandatory.
media Synopsis:  A string 1 to 31 characters long
The type of port media { 100TX, 10FL, 100FX, 1000X, 1000T, 802.11g, EoVDSL, 100TX }.
It provides the user with a description of the installed media type on the port for modular
products. Please note that fiber media may be either Single Mode(SM), Multi Mode(MM),
and may be Short Distance, Long Distance or Very Long Distance with connectors like LC,
SC, ST, MTRJ etc. For the modules with SFP/GBICs, the media description is displayed per the
SFF-8472 specification, if the transceiver is plugged into the module. E.g. 10/100/1000TX
RJ45, 100FX SM SC, 10FX MM ST,1000SX SFP LC S SL M5.
