RUGGEDCOM ROX II
CLI User Guide
Chapter 13
Unicast and Multicast Routing
Viewing the Status of Dynamic Multicast Routing 593
NOTE
A default routing protocol with a local address of 169.254.0.1 always appears when the show
routing status pim-sm command is run. This internal routing protocol is a placeholder to
reserve the source-specific multicast address range.
ruggedcom# show routing status pim-sm
routing status pim-sm
bsr 1.1.1.1
vinterface
LOCAL
INDEX ADDRESS SUBNET FLAGS ID
---------------------------------------------------------------
0 192.168.0.12 192.168.0.0/24 DISABLED
1 169.254.72.4 169.254.72.0/28 DISABLED
2 1.1.1.1 1.1.1.1/32 DR NO-NBR
3 169.254.0.1 169.254.0.0/24 DISABLED
4 192.168.11.1 192.168.11.0/24 DR NO-NBR
5 192.168.12.1 192.168.12.0/24 PIM
192.168.12.2
6 192.168.14.1 192.168.14.0/24 PIM
192.168.14.4
rp
ID PREFIX PRIORITY HOLDTIME
--------------------------------------------
3.3.3.3
225.0.0.1/32 1 105
225.0.0.2/32 1 105
Parameter Description
index Synopsis:  A 32-bit unsigned integer
Virtual interface index.
local-address Synopsis:  A string 1 to 16 characters long
Local address.
subnet Synopsis:  A string 1 to 20 characters long
Subnet.
flags Synopsis:  A string 1 to 128 characters long
Flags indicates virtual interface information.
• DISABLED: The virtual interface is administratively disabled for PIM-SM.
• DOWN: This virtual interface is down.
• DR: Designated router.
• NO-NBR: No neighbor on this virtual interface.
• PIM: PIM neighbor.
• DVMRP: DVMRP neighbor.
Section13.14.3
Viewing the Status of Dynamic Multicast Routing
To view the status of dynamic multicast routing, type:
show routing status multicast
