Siemens RUGGEDCOM ROX II User Manual

Chapter 12
Tunneling and VPNs
RUGGEDCOM ROX II
CLI User Guide
386 Managing VLANs for L2TPv3 Tunnels
Section12.4.6
Managing VLANs for L2TPv3 Tunnels
This section describes how to manage VLANs for L2TPv3 tunnel sessions. Each session supports up to 128 VLAN
membershipts.
CONTENTS
• Section12.4.6.1, “Viewing a List of VLANs”
• Section12.4.6.2, “Adding a VLAN”
• Section12.4.6.3, “Deleting a VLAN”
Section12.4.6.1
Viewing a List of VLANs
To view a list of the VLANs configured for a static or dynamic L2TPv3 tunnel session, type:
show running-config tunnel l2tpv3 [ static | dynamic ] tunnel tunnel-name session tunnel-session vlan
Where:
• tunnel-name is the name of the tunnel
• tunnel-session is the name of the tunnel session
A table or list similar to the following example appears:
ruggedcom# show running-config tunnel l2tpv3 static tunnel 1 session vlan
tunnel
l2tpv3 static tunnel 1
session 1
vlan 4
!
!
!
!
If no VLANs have been configured, add VLANs as needed. For more information, refer to Section12.4.6.2, “Adding
a VLAN”.
Section12.4.6.2
Adding a VLAN
To add a VLAN to a static or dynamic L2TPv3 tunnel session, do the following:
1. Make sure the CLI is in Configuration mode.
2. Add the session by typing:
tunnel l2tpv3 [ static | dynamic ] tunnel tunnel-name session tunnel-session vlan vid
Where:
• tunnel-name is the name of the tunnel.
• tunnel-session is the name of the tunnel session.
• vid is the VLAN ID for the routable logical interface. the value must be between 1 and 4094.
