Siemens RUGGEDCOM ROX II User Manual

Chapter 13
Unicast and Multicast Routing
RUGGEDCOM ROX II
CLI User Guide
462 Configuring RIP
Section13.7.1
Configuring RIP
To configure dynamic routing using the Routing Information Protocol (RIP) daemon, do the following:
1. Make sure the CLI is in Configuration mode.
2. Navigate to routing» rip and configure the following parameter(s) as required:
Parameter Description
enabled Enables the RIP dynamic routing protocol.
default-information-originate The route element makes a static route only inside RIP. This element should be used
only by advanced users who are particularly knowledgeable about the RIP protocol. In
most cases, we recommend creating a static route and redistributing it in RIP using the
redistribute element with static type.
default-metric { default-metric } Synopsis:  An 8-bit signed integer between 1 and 16
Default:  1
Sets the default metric. With the exception of connected route types, the default metric
is advertised when a metric has not been configured for a redistributed route. For
connected route types, the default metric is 1 despite the value of this parameter.
distance-default { distance-default } Synopsis:  A 32-bit unsigned integer between 1 and 255
Sets the default RIP distance.
version { version } Synopsis:  An 8-bit signed integer between 1 and 2
Set the RIP version to accept for reads and send. The version can be either 1 or 2.
Disabling RIPv1 by specifying version 2 is STRONGLY encouraged.
3. Configure prefix lists. For more information, refer to Section13.7.3.3, “Adding a Prefix List”.
4. Configure a network. For more information, refer to Section13.7.4.1, “Configuring a Network”.
5. Configure the prefix list distribution. For more information, refer to Section13.7.8.2, “Adding a Prefix List
Distribution Path”.
6. Configure key chains. For more information, refer to Section13.7.9.3, “Adding a Key Chain”.
7. Configure redistribution metrics. For more information, refer to Section13.7.10.2, “Adding a Redistribution
Metric”.
8. Configure interfaces. For more information, refer to Section13.7.11.2, “Configuring a Routing Interface”.
9. Type commit and press Enter to save the changes, or type revert and press Enter to abort.
Section13.7.2
Viewing the Status of Dynamic RIP Routes
To view the status of the dynamic RIP routes configured on the device, type:
show routing status rip route
If RIP routes have been configured, a table or list similar to the following example appears:
ruggedcom# show routing status rip route | tab
NETWORK TYPE SUB TYPE NEXT HOP METRIC FROM TAG TI
--------------------------------------------------------------------------------
192.168.0.0/24 connected interface 0.0.0.0 1 self 0
192.168.5.0/24 rip normal 192.168.0.3 2 192.168.0.3 0 02
192.168.6.0/24 rip normal 192.168.0.3 2 192.168.0.3 0 02
